100 Ton Low Bed Trailer
100 Ton Low Bed Trailer For Sale
The 100 ton low bed trailer mainly for mining equipment haulage, the loading capacity height only 500mm, very convenient for loading and unloading goods. Large-tonnage axles and heavy-duty tires are adopted and the thickness of the main beam is thickened to ensure heavy load. The axle is used to cross the girder, which effectively reduces the height of the cargo platform from the ground. The increased passing capacity of the vehicle can load objects with larger diameters.
Low Bed Trailer Specification
| Detail | Specification |
|---|---|
| Axle | 4 axles, 4×20,000kg, BPW brand |
| Tire | 315/80R22.5, 16 pcs, TRIANGLE brand |
| Support Leg | 28 tons, JOST brand |
| Kingpin | 3.5 inch heavy duty, JOST brand |
| Brake System | WABCO brand brake valve |
| Suspension | Mechanical leaf spring |
| Material | High strength steel |
| Ladder Type | Spring model |
| Loading Platform | 12000x3000x1300mm (depends on use) |
| Dimension | 15300x3000x3550mm (depends on use) |
100 Ton Low Bed Trailer Axle Detail
The low bed trailer axle is a typical semi-trailer support axle, which plays the roles of bearing, braking, and maintaining driving. Different from ordinary semi-trailer axles, low bed trailer axles are special-purpose axles, which are different from ordinary axles in terms of appearance and performance. The axle brand can optional the BPW, FUWA, ZY heavy duty model axle, thickened brake drum, strong bearing capacity, high braking safety.
100ton Lowbed Shot Blasting Tech
Shot blasting machine is a surface treatment equipment used for rust removal, descaling, roughening, strengthening and increasing roughness. Washable trailer industry accessories include axles, suspensions, leaf springs, outriggers, steel rings, relay valves, rope tensioners, spare tire lifters, tie rods, draw pins, etc. It can clean the welding slag and rust layer on the surface of the workpiece, remove the scale, and increase a certain roughness, which is beneficial to the adhesion process of the subsequent painting surface, extended service life.
100 Ton Low Bed Trailer After Sales Service
Maintenance manual: All our TRUCKMAN low bed trailer have maintenance manual, the maintenance manual clearly records the maintenance methods and precautions of each component which brings convenience for customers to maintain low bed trailer later.
24H service hotline: We have dedicated personnel to answer your emergency calls, provide you with solutions to the problem, and help you solve the problem as soon as possible.
Parts warranty: All of our low bed trailer accessories have a corresponding warranty period to help you reduce maintenance costs. For example: the axle has a warranty of one year or 100,000 kilometers, whichever comes first.
- Price: $16,000-20,000
- Axle: 4 axles, 4x20,000KG
- Tire: 315/80R22.5 etc, 16 pcs
- Support Leg: 28 tons, JOST brand
- Tractor Pin: 3.5 inch heavy duty model
