80 Ton Semi Dump Trailers
80 Ton Semi Dump Trailers For Sale
80 Ton Semi Dump Trailers have 5 axles, per axle loading capacity is 13 tons. FUWA brand. It’s mainly used for mining industry, transport the mining material from site to shipment port. The suspension, rim, leaf spring, chassis etc bearing parts all enhanced, meet the mining site road driving condition. And all main parts adopt the famous and durable brand spare parts, Improve the durability of end dump trailers to bring greater economic benefits to customers.
Specification
| Detail | Specification |
|---|---|
| Axle | 5 axles, 5x13000kg, FUWA brand |
| Tire | 315/80R22.5, 20+1 pcs, TRIANGLE brand |
| Support Leg | 28 tons, JOST brand |
| Kingpin | 3.5 inch heavy duty, JOST brand |
| Brake System | WABCO brand brake system |
| Suspension | Mechanical leaf spring or air suspension |
| Material | Manganese steel |
| Cargo Box | 10000x2300x1500mm, bottom 8mm, side 6mm |
| Loading Capacity | 80,000kg |
| Dimension | 10500x2560x3450mm |
The specification of 80 ton dump trailers only for your reference, can be customized on request.
End Dump Trailers Lifting System
The 80 ton end dump trailer lifting system adopt the front hydraulic lifting type, this structure makes the cargo compartment lifting and lowering with certain stability. Brand is HYVA, the cylinder is characterized by long service life and stable and reliable hydraulic system.
80 Ton Semi Dump Trailers Cargo Box Door
The end dump trailers cargo box door have two model. One is traditional model, used for the sand, gravel, stone etc general cargoes offloading. And another one is two small door, this is design for the offloading the big cargoes, such as big stone etc. It effectively solves the problem of rear door enclosure jammed column goods, and the rear door can also be opened to transport extra-long goods, which improves the transportation efficiency.
End Dump Trailers Customer Feedback
This is our Mauritania customer feedback for the end dump trailers, the dump trailers mainly used for transport the construction material. And loading capacity around 70 tons per time, most of transport road is at desert area. The customer said his dump trailers never had any major problems, very stable and brought in a lot of income for him. He hopes to buy 6 more to expand his transportation fleet.
- Price: $17,900 (price negotiable)
- Axle: 5 axles, 5x13,000
- Tire: 315/80R22.5 etc, 20 pcs
- Support Leg: 28 tons, JOST brand
- Tractor Pin: 3.5 inch heavy duty model
